In the manufacturing process of XC series-circular electrical connectors, how to ensure the accuracy and durability of the bayonet joint?
1. Advanced production equipment and process guarantee
The CNC production workshop equipped by Henglian Factory is equipped with more than 300 various mechanical processing equipment and testing equipment, including several high-precision CNC machining centers. These equipment use advanced CNC technology to achieve micron-level machining accuracy, ensuring that the dimensions of each component of the bayonet joint are accurate. Through precise programming and strict control of machining parameters, we can manufacture precision bayonet joints that meet the requirements of the national military standard GJB2889 and the enterprise standard Q/321202HL003-2009.
The assembly workshop uses a combination of automation and manual work to perform precision assembly to ensure the assembly accuracy of the bayonet joint. In particular, for the key matching parts of the bayonet joint, special assembly tools and fixtures are used to reduce assembly errors and ensure the assembly accuracy and coaxiality of the joint. In addition, a strict inspection process is implemented during the assembly process, and optical measuring instruments are used to monitor the assembly clearance, centering, etc. in real time to ensure that the assembly quality of each joint is optimized.
2. Materials and surface treatment enhance durability
The main components of the bayonet connector, such as the housing, contacts and insulators, are made of high-performance materials. The housing is made of high-strength aluminum alloy or carbon steel, and its strength and corrosion resistance are improved through a specific heat treatment process; the contacts are made of copper alloy or iron alloy, and are silver-plated or gold-plated to improve conductivity and wear resistance. The insulator is made of thermosetting material or glass, which has excellent electrical insulation and heat resistance.
In order to further enhance durability, Henglian has implemented a variety of surface treatment technologies on the housing and contacts of the bayonet connector. Such as galvanized military green passivation, chemical nickel plating and other shielding coatings, as well as anodized black and other non-shielding coatings, these treatments can not only improve the corrosion resistance of the parts, but also improve their surface hardness and wear resistance. For the housing of the glass sintered square plate sealed socket, nickel plating is used to further enhance its protection.
3. Strict inspection and testing to ensure quality
Henglian has advanced and complete inspection equipment in the industry, including spectrometers, metallographic microscopes, etc., for composition analysis and microstructure detection of raw materials to ensure that the material quality meets the design requirements. In addition, the processed parts are inspected for internal defects through non-destructive testing technologies such as ultrasonic flaw detection and magnetic particle flaw detection to ensure that the internal structure of each part is complete and defect-free.
Using universal tensile testing machines, low-temperature impact testing machines, salt spray testers, insulation resistance testers, voltage testers and other equipment, the bayonet joints are tested in many aspects such as mechanical properties, environmental adaptability, and electrical properties. In particular, mechanical life tests such as vibration, impact, and constant acceleration are carried out to ensure that the bayonet joints can still maintain good connection stability and durability under extreme environments. The test standards strictly follow the national military standards and enterprise standards to ensure the reliability and safety of the products.
IV. Support of the quality management system
Henglian Company has passed the GJB9001C-2017 national military standard quality management system certification and ISO 9001, ISO/TS16949 and other quality management system certifications, which indicates that our quality management system has reached the international advanced level. From raw material procurement, production and processing, assembly and testing to finished product delivery, every link follows a strict quality control process to ensure that each batch of XC series - circular electrical connector bayonet connectors can meet or even exceed customer expectations."
